TR-IR NV500Pro: Top Choice from China Suppliers and Factory for Advanced Infrared Solutions
Features
Lightweight and compact design
In a completely dark environment, the farthest observation distance can reach 300 meters
Built-in WiFi for downloading and sharing files on Android or IOS smartphones or tablets
1024x768 high-resolution display provides clear, rich and vivid color images
Powered by one 18650 3.7V Li-ion battery for long continuous operation
1-5x image magnification, flexible selection according to distance
Built-in IR-CUT two-color filter to restore the real image of day and night
Built-in high-brightness, low-power dimmable IR illuminator, which can clearly restore the subject in the dark scene
The infrared lens is not easy to react with metal oxides, acidic substances, air and water, and has good light transmission performance
Product Detail
TR-IR NV500Pro adopts low illumination at night, Sony dynamic CMOS sensor, external IR illuminator. You can obtain excellent observation results both day and night. The novel structure patent design greatly improves the observation effect and observation experience, and the built-in infrared color filter greatly improves the observation effect of the equipment during the day, reduces the overexposure under natural light, and restores more realistically. The built-in light brightness detection sensor can automatically switch between day and night modes according to the light intensity of the environment.
TR-IR NV500Pro strengthens the waterproof design and reaches the protection level of IP67. Using a single built-in rechargeable battery with a low power consumption design, the continuous working time can reach more than 5 hours, meeting the requirement of using without changing the battery all night. In addition, it has advanced fast start-up performance, fast imaging in 3 seconds after booting, which significantly improves the user's quick response ability. The high refresh rate design enables the operator to obtain the ability to observe fast-moving targets. At the same time, equipped with high-quality and high-performance objective lens, it ensures safety and reliability without fear of strong light. When installed on a tripod for long-distance night observation, the night observation distance can reach 300 meters, and it can be connected to cameras, video cameras, and wireless image transmission equipment.
TR-IR NV500Pro is designed with a 3.5x-17.5x(5x)35mm digital rifle scope. The built-in WiFi module allows users to record and share videos, and comes with a Type-C interface for external power supply and data copying at the same time. It supports video recording and exporting. It is mainly used in outdoor night shooting, hunting, outdoor adventure, search and rescue, and can be used instead of a sniper scope to complete night hunting.
Frequently Asked Questions
What is the maximum observation distance of the TR-IR NV500Pro in complete darkness?
In a completely dark environment, the farthest observation distance of the TR-IR NV500Pro can reach up to 300 meters.
How long does the battery last, and what type of battery does it use?
The device is powered by a single 18650 3.7V Li-ion battery. Thanks to its low power consumption design, it provides a long continuous working time of more than 5 hours.
Can I share videos and photos captured by the device to my phone?
Yes. The TR-IR NV500Pro has a built-in WiFi module that allows you to download and share files on Android or iOS smartphones and tablets, and a Type-C interface for data copying.
Is the TR-IR NV500Pro waterproof?
Yes, it features a reinforced waterproof design that reaches the protection level of IP67, making it reliable in various outdoor environments.
What are the main applications of this digital rifle scope?
It is designed for outdoor night shooting, hunting, outdoor adventure, search and rescue, and can also be used as a replacement for sniper scopes to complete night hunting.
specification
| Product name | Adaptor |
| Brand | Ten Rings |
| Model | TR-AD48 |
| Compatible model | TR-IR NV200, TR-IR-LRF NV201 |
| Diameter | 48mm |
| Material | Aluminum alloy |
